GRAIN-ORIENTED ELECTRICAL STEEL In a certain magnetization field, strong directivity, rolling direction of the lowest iron loss, the highest permeability, magnetic induction value is high.  Oriented silicon steel has a silicon content of about 3%. It also requires that the content of oxide inclusions in the steel be low and must contain certain inhibitors.

Category:



Product NameCold Rolled Grain Oriented Silicon Steel
StandardB23G110, B27G120, B35G155, B23R080-B27R095
Thickness0.23mm-0.35mm
Width20mm-1250mm
LengthCoil Or As Required
TechniqueCold Rolled
Surface TreatmentCoated
ApplicationWidely used in transformers, generators, various household motors and micro-motors, etc.
Special UseSilicon Steel
SampleFor Free

Magnetic properties
The magnetic properties of the product is featured by its low core loss, high permeability and excellent application performance
Thickness tolerance
The good thickness tolerance is characterized by small difference in thickness in a direction parallel to the direction of rolling, small difference in thickness in a direction perpendicular to the direction of rolling, and high lamination factor.
Processing property
The product is suitable for punching and cutting with excellent dimensional tolerance.
Insulation coating
The insulation coating has small color deviation, good adhesiveness and excellent resistance to heating and corrosion with high insulation coating resistance. There are several types of insulation coating available for production. According to the test results performed by the professional inspection organizations, the contents of hazardous substances comply with all the prevailing international and domestic environment protection laws and regulations including EU RoHS and REACH regulations.
